Toepasselijke Industrie: | Hotels, Bouwmateriaalwinkels, MachinesReparatiewerkplaatsen, Productieinstallatie, Voedsel & Drankfa | Toonzaalplaats: | Egypte, Canada, Turkije, Verenigde Staten, Italië, Duitsland, Vietnam, Indonesië, Pakistan, India, T |
---|---|---|---|
Video uitgaand-inspectie: | Verstrekt | Het Rapport van de machinestest: | Verstrekt |
Marketing Type: | Nieuw Product 2020 | Garantie van kerncomponenten: | 1 jaar |
Kerncomponenten: | PLC, Motor | Voorwaarde: | Nieuw |
Gewicht: | 740 kg | Garantie: | 1 jaar |
Gewicht (kg): | 740 kg | Model: | Nj-130-2,0 |
Nuttige lading: | 130kg | Extra lading op voorarm (Kg): | 15kg |
Maximum horizontaal bereik (mm): | 2050 | De flens van de hulpmiddelkoppeling: | ISO 9409 - 1 - 125 |
Herhaalbaarheid (mm): | 0,07 | Slag (Snelheid) op As 6: | +/- 2700° (230°/s) |
Beschermingsklasse: | IP65/IP67 | Opzettende Positie: | Vloer/Plafond/het Hellen |
Aantal assen: | 6 | Haven: | Shanghai |
item | value |
Applicable Industries | Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Printing Shops, Construction works , Advertising Company |
Showroom Location | Egypt, Canada, Turkey, United States, Italy, Germany, Viet Nam, Indonesia, Pakistan, India, Thailand, Japan |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Marketing Type | New Product 2020 |
Warranty of core components | 1 Year |
Core Components | PLC, Engine |
Condition | New |
Place of Origin | China |
Brand Name | Comau |
Weight | 740kg |
Warranty | 1 Year |
Model | NJ-130-2.0 |
Payload | 130kg |
Additional load on forearm (Kg) | 15kg |
Maximum horizontal reach (mm) | 2050 |
Tool coupling flange | ISO 9409 - 1 - A 125 |
Repeatability (mm) | 0.07 |
Stroke (Speed) on Axis 6 | +/- 2700° (230°/s) |
Protection class | IP65/IP67 |
Mounting position | Floor / Ceiling / Sloping |
Number of axes | 6 |
